Aluminum Composite Panel (ACP)

ABOUT ALUMINIUM COMPOSITE PANELS

ACPs are highly durable with extensive aesthetic traits. They come under the head of metal composite material. MCM can be of Aluminium, Copper, Zinc, Stainless Steel and Titanium. Aluminium Composite Panel is a compressed panel constituting of a core polyethylene material sandwiched between two sheets of aluminium coils. Aluminium coils are made from aluminium plates and plated through chemical cleanout, then coloured with polyester and fluorocarbon coating and dried through high temperatures. We use 1100 H 18/3003 series Aluminium Alloy and KYNAR 500 PVDF.

ACP (Aluminium Composite Panel) cladding is commonly used for architectural and construction purposes. ACP cladding can be wrapped around structural columns, providing a decorative and protective cover. This is commonly seen in commercial buildings and public spaces.

ACP sheet prices differ on sizes usability & thickness of materials. For more information, you can contact us here.

With Timex Bond, you will never run out of options. The dexterity, durability and diversity of colours and textures is simply outstanding. Definitely a dependable pick!

• A wide spectrum of colour charts
• Fulfilling all International norms
• Available in a range of Aluminium Composite Panels
• Fire-Resistant ACP: Constitutes of non-toxic polyethylene core
• Fire-Retardant ACP: Constitutes of A2 compound core
• Conforming to ASTM Standards
• Efficiently executed prestigious projects all over India

THE ADVANTAGES

Over the years Timex Bond has gained a competitive edge by consistently offering:

• Qualitative products
• Voluminous warehousing
• Ability to execute bulk order
• High-end packaging
• Efficient network of distributors
• Prompt delivery

Developers, designers and architects worldwide vouch for the adaptability and creative flexibility ACPs offer, with advantages far outweighing traditional materials like stones, tiles and paint.

• Lightweight & Rigid
• Sound Insulation by 25 Decibels
• Withstand Extreme Weather
• Excellent Surface Smoothness & Flatness
• Corrosion Resistance
• Good Thermal Insulation
• Great Impact Resistance
• Can Be Easily Fixed To All Types Of Cladding Applications
• Cost Effective
• Bare Minimum Maintenance

MANUFACTURING PROCESS

• Blending
• Extrusion
• Calendering
• Coiler
• Rolling
• Chilling
• Protection Lamination
• Finished Goods

COATING

• PVDF Paint Coating

An Essential Quality Constituent

Few Advantages:

• Super weather-ability: Specially built to maintain their look and withstand extreme weather.
• High peel strength, advanced technology and raw materials: The peel strength of our PVDF ACP exceeds national standards.
• Impact resistance: The Carbon/Fluorine bond, one of the strongest molecular bonds known, is the key to Kynar 500 resin’s unsuppressed thermal, chemical and ultraviolet resistant properties.
• Even coating and customized color: With a combination of carbon-fluorine bonds (providing stability) and carbon-hydrogen bonds, a unique structure with balanced properties is created that makes PVDF particularly suitable as a base for liquid coatings. oils.
• Maintenance free: PVDF is inherently inert and has the ability to withstand long-term UV and gamma radiation, resulting in excellent colour and gloss retention without chalking. PVDF also resists acids, alkalis and oils.

Kynar 500 has following properties:

• High Thermal & Chemical Resistance
• High Electrical Resistivity
• Resistance to UV Light
• Low Refractive Index
• High Purity
• Good Abrasion Resistance
• Good Moisture and Fungus Resistance
• Low Surface Energy
• Exceptional Weathering Resistance
• Low Coefficient of Friction

BONDING
Strong Adhesive Film

Timex Bond panels adopt the first grade adhesive film supplied by DuPontTM. Film thickness is > 80 micron for a 0.5 mm aluminium sheets and 50 micron for a 0.25 mm aluminium sheets. The adhesive used is of good quality and aids the durability and strength of the Aluminium Composite Panels.
